Product Description
Baldwin hydraulic filters offer superior protection for your engine-powered equipment. Improving system fluid cleanliness levels, providing better cold start performance and meeting service interval expectations are the primary objectives in the design of Baldwin hydraulic filters. Baldwin hydraulic filters utilize cellulose, synthetic and blended media to meet these performance specifications. A full range of filters is available to accommodate low, medium and high pressure applications
Technical Specifications
| Product Type | Maximum Performance Glass Hydraulic Spin-on |
|---|---|
| Notes | Can be used with OB1314 and OB1316 bases (requires optional G286-C gasket). |
| Thread Size | 1 1/2-16 |
| Outside Diameter | 5 1/16 (128.6) |
| Length | 6 31/32 (177.0) |
| Gasket | Furnished Gasket: G369-B, G447; Optional Gasket: G286-C, G369-V, G372, G483, G704, G710 |
| Micron Rating | 5 Nominal; 20 Absolute |
| Application | John Deere Equipment |
| Compatible Competitor Part Number | John Deere AT100973, RE45864 |
| Brand | Baldwin |
Warranty Information
1 Year Manufacturer WarrantyProduct Videos
Custom Field
Part Status Active
Oversized No
Manufacturer Baldwin Filters
Class Description Hydraulic Filter Replacement Parts
Group Name Maximum Performance Glass Hydraulic Spin-on
Package Qty 1
