Product Description
Baldwin hydraulic filters offer superior protection for your engine-powered equipment. Improving system fluid cleanliness levels, providing better cold start performance and meeting service interval expectations are the primary objectives in the design of Baldwin hydraulic filters. Baldwin hydraulic filters utilize cellulose, synthetic and blended media to meet these performance specifications. A full range of filters is available to accommodate low, medium and high pressure applications
Technical Specifications
| Product Type | Stainless Steel Mesh Hydraulic Spin-on |
|---|---|
| For Use With | OB1313, OB1314, OB1315, OB1316 bases (requires optional G286-C gasket). |
| Thread Size | 1 1/2-16 |
| Outside Diameter | 5 1/16 (128.6) |
| Length | 10 3/4 (273.1) |
| Gasket | Furnished Gasket: G369-B; Optional Gasket: G286-C, G369-V, G372, G447, G483, G704, G710 |
| Micron Rating | 144 Nominal |
| Application | Fiat-Allis Equipment |
| Compatible Competitor Part Number | Fiat 73133001; Zinga LE100 |
| Brand | Baldwin |
Warranty Information
1 Year Manufacturer WarrantyProduct Videos
Custom Field
Part Status Active
Oversized No
Manufacturer Baldwin Filters
Class Description Hydraulic Filter Replacement Parts
Group Name Stainless Steel Mesh Hydraulic Spin-on
Package Qty 1
