Product Description
"Baldwin hydraulic filters offer superior protection for your engine-powered equipment. Improving system fluid cleanliness levels, providing better cold start performance and meeting service interval expectations are the primary objectives in the design of Baldwin hydraulic filters. Baldwin hydraulic filters utilize cellulose, synthetic and blended media to meet these performance specifications. A full range of filters is available to accommodate low, medium and high pressure applications
Technical Specifications
| Product Type | Maximum Performance Glass Hydraulic Spin-on |
|---|---|
| Notes | Rated 1000 PSI minimum burst.; NOT interchangeable with BT8851-MPG. |
| For Use With | OB8711, OB8712, OB8720, OB8721, OB8722, OB8724, OB8731, OB8732, OB8741, OB8742, OB8743, OB8744, OB8745, OB8746 filter bases. |
| Thread Size | 1 3/8-12 |
| Outside Diameter | 3 3/4 (95.3) |
| Length | 9 17/32 (242.1) |
| Gasket | Attached Gasket: [1] Attached |
| Micron Rating | 5 Nominal; 20 Absolute |
| Application | Case, Case-International, Caterpillar, Daewoo, Fiat-Allis, John Deere, Kawasaki, New Holland, Steiger, Thomas Equipment |
| Compatible Competitor Part Number | Case D94236; Caterpillar 9T5916; Fiat 73144499; John Deere RE34958 |
| Brand | Baldwin |
Warranty Information
1 Year Manufacturer WarrantyProduct Videos
Custom Field
Part Status Active
Oversized No
Manufacturer Baldwin Filters
Class Description Hydraulic Filters
Group Name Maximum Performance Glass Hydraulic Spin-on
Package Qty 1
