Product Description
Baldwin hydraulic filters offer superior protection for your engine-powered equipment. Improving system fluid cleanliness levels, providing better cold start performance and meeting service interval expectations are the primary objectives in the design of Baldwin hydraulic filters. Baldwin hydraulic filters utilize cellulose, synthetic and blended media to meet these performance specifications. A full range of filters is available to accommodate low, medium and high pressure applications.
Technical Specifications
| Product Type | Maximum Performance Glass Hydraulic Spin-on |
|---|---|
| Notes | Rated 1000 PSI minimum burst.; Dome end accepts 1/2 In. socket driver. |
| Thread Size | 1 3/8-12 |
| Outside Diameter | 3 3/4 (95.3) |
| Length | 6 11/32 (161.1) |
| O-ring | [1] Included |
| Micron Rating | 5 Nominal; 20 Absolute |
| Application | John Deere Tractors |
| Compatible Competitor Part Number | John Deere AL156625; Mann & Hummel WH945 |
| Brand | Baldwin |
Warranty Information
1 Year Manufacturer WarrantyProduct Videos
Custom Field
Part Status Active
Oversized No
Manufacturer Baldwin Filters
Class Description Hydraulic Filters
Group Name Maximum Performance Glass Hydraulic Spin-on
Package Qty 1
