Product Description
"Baldwin hydraulic filters offer superior protection for your engine-powered equipment. Improving system fluid cleanliness levels, providing better cold start performance and meeting service interval expectations are the primary objectives in the design of Baldwin hydraulic elements. Baldwin hydraulic elements utilize cellulose, synthetic and blended media to meet these performance specifications. A full range of filters is available to accommodate low, medium and high pressure applications.
Technical Specifications
| Product Type | Maximum Performance Glass Hydraulic Element with Blank Band |
|---|---|
| Outside Diameter | 5 29/32 (150.0) |
| Inside Diameter | 4 1/16 (103.1) |
| Length | 17 1/32 (432.6) |
| Gasket | Attached Gasket: [1] Attached |
| Micron Rating | 5 Absolute |
| Application | Volvo Excavators |
| Compatible Competitor Part Number | Volvo 14539482, 14688861; Donaldson P502494; Fleetguard HF3551 |
| Brand | Baldwin |
Warranty Information
1 Year Manufacturer WarrantyProduct Videos
Custom Field
Part Status Active
Oversized No
Manufacturer Baldwin Filters
Class Description Hydraulic Filter Elements
Group Name Maximum Performance Glass Hydraulic Element with Blank Band
Package Qty 1
